Key Features
- Measures real-scale fires — warehouses, commodities, furniture, vehicles — with a Heat Release Rate (HRR) of 1 to 10 MW, extendable up to 10–30 MW, against the roughly 0.5 MW ceiling of a standard Cone Calorimeter
- Built to ISO 24473 (open calorimetry, fires up to 40 MW), ISO 9705 (Room Corner Test), EN 13823 (Single Burning Item), EN 45545 (railway fire protection) and EN 50399 (cables under fire conditions)
- Bi-directional velocity probe and a flange-type measuring station (sampling probe, smoke-density system) in corrosion-resisting materials measure heat release by oxygen consumption even through hot, turbulent combustion gas
- Heated gas-sampling line with Teflon hose prevents moisture condensation and corrosion while carrying sampling gas to the analyser rack up to 50m away, with a minimum 40 PSI transfer pressure
- Reports Heat Release Rate, Smoke Production Rate, soot mass, O₂/CO/CO₂ consumption and yield, plus other toxic gases via FT-IR
About the Large Scale Calorimeter
The Large Scale Calorimeter (model FT-LSC-608) from FT Solutions Co., Ltd. (FESTEC), South Korea, measures heat release in real-scale fires by oxygen-consumption calorimetry. Its Heat Release Rate range is 1 to 10 MW, extendable to 10–30 MW, so complete commodities, furniture, vehicles and warehouse-type fire loads can be burned and measured, instead of the small 100 × 100 mm specimens used in a cone calorimeter.
The system is built for ISO 24473 (open calorimetry), ISO 9705 (room corner test), EN 13823 (single burning item), EN 45545 (railway fire protection) and EN 50399 (cables under fire conditions). It reports Heat Release Rate, smoke production rate, soot mass, O₂, CO and CO₂ consumption and yield, and other toxic gases by FT-IR. A bi-directional velocity probe and a corrosion-resistant flange-type measuring station keep readings dependable in hot, turbulent combustion gas, and a heated sampling line with Teflon hose carries the gas to an analyser rack up to 50 m away.
Large Scale Calorimeter specifications
| Model | FT-LSC-608 |
|---|---|
| Manufacturer | FT Solutions Co., Ltd. (FESTEC), South Korea |
| Heat Release Rate | 1 to 10 MW, extendable to 10–30 MW |
| Sampling rack (mm) | 2,000 × 800 × 1,800 |
| Control rack (mm) | 600 × 750 footprint |
| Power | AC 220 V, 50/60 Hz, 60 A |
| Weight | About 450 kg (sampling rack), about 130 kg (control rack) |
| Utilities | Propane gas, CO (0.8%) / CO₂ (8%) gas, nitrogen gas, heptane, compressed air, hood, duct and dust collector |
Specifications are as published by the manufacturer, FT Solutions Co., Ltd. (FESTEC). Download the product brochure or contact us to confirm the configuration for your laboratory.
Large Scale Calorimeter: frequently asked questions
What heat release range does the FT-LSC-608 cover?
1 to 10 MW as standard, extendable to 10–30 MW, measured by oxygen consumption. A cone calorimeter tests small 100 × 100 mm specimens, which is why a large scale calorimeter is used for whole products and real-scale fires.
Which standards is the Large Scale Calorimeter designed for?
ISO 24473 (open calorimetry), ISO 9705 (room corner test), EN 13823 (single burning item), EN 45545 (railway fire protection) and EN 50399 (cables under fire conditions).
What results does the large scale calorimeter report?
Heat Release Rate, smoke production rate, soot mass, O₂, CO and CO₂ consumption and yield, plus other toxic gases through FT-IR.
What are the installation requirements for the FT-LSC-608?
The sampling rack is 2,000 × 800 × 1,800 mm and weighs about 450 kg; the control rack has a 600 × 750 mm footprint and weighs about 130 kg. The system needs an AC 220 V, 50/60 Hz, 60 A supply, propane gas, CO/CO₂ gas, nitrogen gas, heptane, compressed air, and hood, duct and dust-collector extraction.
Where can I buy the Large Scale Calorimeter (FT-LSC-608) in India?
Multiflo Instruments, based in Navi Mumbai, supplies FT Solutions (FESTEC) test equipment across India. Our team can advise on the FT-LSC-608, send a quotation, and arrange installation, training, calibration and after-sales service. Use the Contact Us button or call +91-22-44516175.
