Key Features
- The GMX is a portable gloss meter conforming to ISO 2813, ASTM D523 and JIS Z8741
- Available in 60°, 20° and 75° geometries
- Built-in rechargeable batteries, compact size and light weight
- 1,000 data points can be saved
- Directly print to small printer by RS-232C output
- Applications: automobiles, painted surfaces, building materials, electric materials, resin molding, dental materials, metal plates, plated surfaces, tiles, porcelains and ceramics
About the Murakami GMX Color and Gloss Meter
The GMX series from Murakami Color, Japan, is a portable gloss meter conforming to ISO 2813, ASTM D523 and JIS Z8741. It is available in 60°, 20° and 75° geometries, and it is compact and light, with built-in rechargeable batteries.
Up to 1,000 data points can be saved, and results can be printed directly to a small printer through the RS-232C output. Listed applications include automobiles, painted surfaces, building materials, electric materials, resin molding, dental materials, metal plates, plated surfaces, tiles, porcelains and ceramics.
GMX Series specifications
| Model | GMX Series |
|---|---|
| Manufacturer | Murakami Color, Japan |
| Type | Portable gloss meter |
| Standards | ISO 2813, ASTM D523, JIS Z8741 |
| Geometries | Available in 60°, 20° and 75° |
| Power | Built-in rechargeable batteries |
| Size and weight | Compact size and light weight |
| Data storage | 1,000 data points |
| Output | Direct printing to a small printer through RS-232C |
| Applications | Automobiles, painted surfaces, building materials, electric materials, resin molding, dental materials, metal plates, plated surfaces, tiles, porcelains and ceramics |
Specifications are as published by the manufacturer, Murakami Color. Contact us to confirm the configuration for your laboratory.
Gloss meter: frequently asked questions
Which standards does the Murakami GMX gloss meter conform to?
ISO 2813, ASTM D523 and JIS Z8741.
Which measurement geometries are available?
The GMX is available in 60°, 20° and 75° geometries.
How many readings can the GMX store, and how are results printed?
It can save 1,000 data points, and the RS-232C output prints directly to a small printer.
What surfaces and materials can the GMX measure?
Listed applications include automobiles, painted surfaces, building materials, electric materials, resin molding, dental materials, metal plates, plated surfaces, tiles, porcelains and ceramics.
Where can I buy the Murakami GMX gloss meter in India?
Multiflo Instruments, based in Navi Mumbai, supplies Murakami Color instruments in India. Our team can advise on the GMX series, send a quotation, and arrange installation, training, calibration and after-sales service. Use the Contact Us button or call +91-22-44516175.
